Rapid PRO series LRP and LRN

Suspended modulating heater.

Rapid PRO series LRP and LRN

Suspended modulating heater.

The Rapid Pro is a more advanced version of our Plus and Rapid suspended heaters that’s designed to meet the new requirements of the EU 2281/2016 legislation, in force since 01/01/2021 (ErP 2021).

Rapid Pro heaters are modulating heating systems that use a continuous modulation system to better optimise the heating system and reduce the stratification of heat within the work environment, without condensation.

Using the best premix burner technology and the best raw materials, we offer our Partners and End Users a heating solution that:

  • Will last over time.
  • Meets to the concrete needs of the markets.
  • Meets the increasingly restrictive requirements of the national and European regulations.
  • Are designed and certified for working with mixture of Gas and Hydrogen (up to 20%).

NEW SUSPENDED HEATERS LRN SERIES

  • lower transport and installation costs thanks to the small dimensions with respect to the previous versions with equal powers;
  • improved combustion and burner components accessibility thanks to the new Venturi tube, to the gas valve position and to the single electrode;
  • designed and certified for working with mixture of Gas and Hydrogen (up to 20%), thus really meeting the need of new green energies.

The Rapid Pro is the new solution developed by Apen Group based on over 50 years of experience.

Attention
Do not install where leakages of oils in the atmosphere (e.g.dietary fats) are present.
Do not use in particularly aggressive environments or with potentially corrosive atmospheres (for example in environments with animal or livestock farms) which can generate corrosion or rust on the metal parts of the unit heater components.
Do not use in extreme operating conditions or in any case outside the operating fields foreseen by the manufacturer.





Technical characteristics

  • Output ranging from 9 kW to 92 kW;
  • Sealed combustion circuit;
  • AISI 441 stainless steel combustion chamber, and AISI 441 low-carbon stainless steel heat exchanger tube and flue collection box;
  • Efficiency up to 97% (ncv);
  • Premixed gas modulating burner, low NOx emissions (class 5) in compliance with the EN 1020 2009 standard;
  • Microprocessor-controlled electronic control board with continuous heat output modulation, which provides for an energy savings of up to 40%;
  • Excellent reduction of air stratification;
  • An advanced air/gas mixing technique guarantees the heater’s complete safety;
  • Safety thermostat;
  • 230V/1ph/50Hz power supply;
  • Compliant with all the applicable EC regulations.

Request information

Card Specifications

Rapid PRO serie LRN

MODELAIR FLOW mc/hMIN NOMINAL HEAT INPUT kWMAX NOMINAL HEAT INPUT kWMIN USEFUL HEAT OUTPUT kWMAX USEFUL HEAT OUTPUT kWHi EFFICIENCY (N.C.V.) min %Hi EFFICIENCY (N.C.V.) max %
LRN0182.00010,017,49,615,996,191,2
LRN0282.70015,627,015,024,696,091,2
LRN0353.20019,634,818,931,796,291,2
LRN045460026,244,825,240,996,291,3

Rapid PRO serie LRP

MODELAIR FLOW mc/hMIN NOMINAL HEAT INPUT kWMAX NOMINAL HEAT INPUT kWMIN USEFUL HEAT OUTPUT kWMAX USEFUL HEAT OUTPUT kWHi EFFICIENCY (N.C.V.) min %Hi EFFICIENCY (N.C.V.) max %
LRP0554.50029,852,228,848,196,892,1
LRP0757.80044,473,542,567,595,891,8
LRP1027.90051,8100,049,991,196,491,1
